Grace -700 heavy-duty public transport escalators are suitable for public transport systems such as airports, railway stations, and shopping centers, meeting passenger flow needs and equipment safety tests at different times.
| Specification | GRACES-HD/700 | |||||
| Lifting height range/m | 3≤H≤25 | |||||
| Use segment length/m | -- | |||||
| Tilt angle/° | 27.3/30 | |||||
| Nominal width/mm | 1000 | |||||
| Nominal speed/m/s | 0.5/0.65 | |||||
| Applicable environment | Indoor/Outdoor | |||||
| The type of work | Public transport heavy-duty type | |||||
| Handrail structure | Vertical armrests | |||||
| Stainless steel diagonal armrest | ||||||
| Drag method | VVVF | |||||
| Startup mode | Frequency conversion low speed Frequency conversion self-starting | |||||
| Number of horizontal steps as standard | H≤6m | 4 | ||||
| H>6m | 4 | |||||
| Pedal depth/mm as standard | -- | |||||
| Additional brakes | H≤6m | Yes | ||||
| H>6m | Yes | |||||
| Truss deflection | ≤1/1500 | |||||
| Safety factor for moving parts | ≥8 | |||||
